Hreinsloftsryksuga AL-KO POWER UNIT 350 P-FU

AL-KO Reinluftentstauber AL-KO POWER UNIT 350 P-FU

with compressed air cleaning and frequency converter
Startup with frequency converter,
Pressure transmitter for demand-based control

Fsdjxpximopfx Adhjpr
Pre-separator integrated,
Automatic fire extinguishing system integrated

Efficient and economical: Large-capacity compressed air tank with
fast-acting diaphragm valves for effective
OPTI JET filter cleaning and minimal compressed air consumption.
So simple and so effective: OPTI JET cleaning and
filter bags with snap ring closure.
Exceptionally economical: energy-efficient drives according to IE3
Safe in case of emergency: maintenance-friendly fire extinguishing system.
Extremely quiet operation: sound-insulated air recirculation from
AL-KO.
All options available: PLC control for manual and automatic modes.
Countless options from machine recognition to
gate actuation to frequency-controlled operation,
to name just three examples.
Nothing left to chance: collection container with
inspection window.
Practical in every detail: container fastening with ergonomically
shaped clamping lever.
Expandable at any time: retrofit for discharge via
briquetting press or rotary valve possible.

- High extraction performance
- Compact footprint
- 100% air recirculation without temperature loss
- (Residual dust < 0.1 mg/m³)
- Integrated pre-separator and expandable control system
- Optimal filter cleaning
- Minimal noise level
- Optional: patented fill level monitoring
- Maintenance-friendly, certified automatic fire extinguishing system
- Dust barrier for dust-free bin changes
- (Optional: safety locking system for the containers)
- Freely configurable module exchange and expandable

----- Technical Data -----
Extraction nozzle diameter: 350 mm,
Nominal air flow rate: 6,927 m³/h,
Maximum air flow rate: 8,500 m³/h,
Maximum negative pressure: 2,543 Pa,
Filter surface: 73 m²,
Chip collection volume: 3 x 250 liters,
Number of bags: 3,
Motor 400 V: 11.0 kW,
Dimensions (LxWxH): 3,340 x 1,058 x 2,351 mm,
Sound pressure level: 71 dB(A),
Weight: 999 kg,
according to: GS - HO - 07
