DOOSAN VC 630/5Ax
DOOSAN VC 630/5Ax

Name: DOOSAN VC 630/5Ax
Brand: DOOSAN
Availability: InStock

Framleiðsluár

2013

Ástand

Notað

Staðsetning

Portúgal

Upplýsingar um vélina

Heiti vélar:: DOOSAN VC 630/5Ax

Framleiðandi:: DOOSAN

Gerð:: VC 630/5Ax

Framleiðsluár:: 2013

Ástand:: tilbúinn til notkunar (notaður)

Verð og staðsetning

Staðsetning:: , Portúgal

Hringdu

Tæknilegar upplýsingar

Spindilhraði (hámark):: 12.000 snúningur/mín.

Heildarhæð:: 3.295 mm

Heildarbreidd:: 3.200 mm

Heildarþyngd:: 12.500 kg

X-áss færi:: 650 mm

Y-áss færsla:: 765 mm

Förfaravegalengd Z-áss:: 520 mm

Vörulengd (hámark):: 3.537 mm

Verkfæraþyngd:: 8.000 g

Fjöldi rifa í verkfærageymslu:: 40

Fjöldi ása:: 5

Tilboðsupplýsingar

Auglýsingarauðkenni:: A22540877

Tilvísunarnúmer:: PT-MIL-DOO-2013-00002

Uppfærsla:: síðast þann 12.08.2026

Lýsing

This 5-axis DOOSAN VC 630/5Ax was manufactured in 2013. It features an impressive X-axis travel of 650 mm, Y-axis travel of 765 mm, and Z-axis travel of 520 mm. The machine includes a maximum workpiece weight capacity of 500 kg and a spindle speed of up to 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the DOOSAN VC 630/5Ax universal machining centre we have for sale. Contact us for further details.

• CNC controls available: FANUC 31i-5, HEIDENHAIN iTNC 530, SIEMENS 840Dsl
• Travels: A (tilt) +30° to -120°; C (rotation) 360°
• Spindle nose to table: Standard 160–680 mm; with APC 210–730 mm
• Spindle center to column guideway: 220 mm
• Rapid traverse: X/Y/Z 40/40/36 m/min; A/C 20/30 rpm
• Cutting feed: X/Y/Z 18,000 mm/min; A/C 7,200 deg/min
• Table: Ø630 mm (standard); APC pallet 500 x 500 mm
• Max workpiece: 500 kg; dimensions standard Ø730 x 500 mm; with APC Ø730 x 450 mm
• Min table indexing: 0.001°
• Spindle: Built-in; 12,000 rpm (optional 20,000 rpm); ISO #40 7/24 BIG-PLUS (optional HSK-A63)
• Max spindle torque: 204 N·m
• Spindle motor power: FANUC 22/18.5 kW; HEIDENHAIN 23.5/18 kW; SIEMENS 30/24 kW
Fpjdezt Rwqspfx Acyok
• ATC: MAS403 BT40 (options CAT40/DIN40); 40 tools (options 60/81/101/121); max tool Ø adj 80 mm, without adj 125 mm; max tool length 300 mm; fixed address; tool-to-tool 1.0 s; chip-to-chip 8.5 s
