GIBEN ONIX SP 90 CHALLENGE LINE

Code: 0188
Brand: GIBEN
Model: ONIX SP 90 CHALLENGE LINE - CE Standard

Automatic horizontal panel saw with clamps for cutting wood panels, multilayer panels, furniture, composite materials, sandwich panels and various materials - CE Standard

Cutting dimensions mm 4400 x 4300
Blade projection mm 90
Blade carriage: feed speed 5/100 mt/min - return speed 100 mt/min
Main blade diameter mm 350 - Motor Hp 12,5
Scoring blade diameter 180 mm - Motor Hp 2
Pusher: feed speed 1/25 mt/min - return speed 60 mt/min
Frontal loading of panel stack and pusher with clamps
N° 3 front air cushion tables
Automatic pusher with side upper guides equipped with 7 pneumatic clamps. The steel clamps keep the stack blocked throughout the panel sizing cycle up to the last trim cut.
Automatic lateral aligner
Automatic adjustment of the blade projection in relation to the height of the pack to be sawn.
Electronic control of the speed and position of the saw carriage
Hsdew Ec Riopfx Af Rsng
Easy access to the saw carriage
Pneumatic unit for rapid tool removal
G-VISION control: Giben machine control software installed on a PC. Multi-tasking Microsoft Windows XP/2000/NT operating system for easy networking
Advantages: Sequential control of cutting patterns, number of panels, and pattern sequence change. Parametric control of the feed speed of the saw carriage according to the stack height and trim width. Direct control of machine functions. Setting of cutting patterns.
Suction: diameter suction inlets 200 mm
Compressed air 6-7 bar
Overall dimensions of assembled machine: mm 6400 x 7500 x 1800 h
Overall dimensions for transport: machine mm 6500 x 1500 x 1800 h - pusher mm 5200 x 1200 x 1200 h
Total weight kg 3200
