CNC dýptarholuborvél með búnaði

IXION TL 1001

IXION TL 1001
CNC Deep Hole Drilling Machine

Year of manufacture: 2008
Control system: MITSUBISHI M530
Machine number: 950521
Drilling depth (Z), CNC controlled: 1,000 mm
Drilling unit (Y), vertically adjustable: 800 mm
Table size: 1,200 mm x 700 mm
Table load capacity: 3,000 kg
Table longitudinal travel (X): 1,000 mm
Table transverse travel (W): 1,000 mm
Table rotation: 360°
Spindle: SK 40
Spindle speed: 100 – 4,000 rpm
Maximum drilling capacity in steel: 25 mm
Maximum thread cutting in steel: M20
Milling in steel is possible
Weight: approx. 3,500 kg

Equipment:
Compact belt filter KBF
Electronic handwheel
Coolant system
Chip conveyor KBF 270 P50

Included in scope of delivery:
Deep hole drilling tools
Workstation with:
Holders / Fixtures / Supports / Sealing discs
Operating manual / Documentation
Machine parameters on storage medium

Fgedpfxsx E Si Is Afqok
Equipment, technical data, installation & transport – see PDF. Illustration, content, and information are provided without guarantee and are therefore non-binding.

All other accessories visible in photos and videos are not included in the scope of delivery and are therefore not part of this sale. The scope of delivery only includes the accessories explicitly listed here, in the order confirmation, and the invoice.

FCA (Free Carrier Truck Loaded) D-04643 Geithain
Packaged only
Delivery time: immediately
Subject to prior sale / Payment due immediately upon conclusion of sale.

Þessi auglýsing var sjálfvirkt þýdd. Villa í þýðingu gæti verið til staðar.
