Hurðablaðsmótunarvél Kraft / Costa / IMA / Bürkle / Homag

Kraft / Costa / IMA / Bürkle / Homag

Door panel postforming line
Note: The line began series production in 2022; at this point, all machines were technically synchronized and, if necessary, overhauled.
Door panel postforming line consisting of:
Portal loading system
Manufacturer: Kraft
Year of manufacture: 2019
Technical data
- with vacuum lifter
- 2 infeed roller conveyors
- one transport roller conveyor for further transport

Wide belt sanding machine
Manufacturer: Costa
Type: KK7 CT CT 1350
Year of manufacture: 2018
consisting of:
Wide belt sanding machine, sanding from below
Technical data
- contact roller
- electronic shoe sanding unit
- cleaning brush
- intermediate transport belt, length approx. 3000 mm

Wide belt sanding machine, sanding from above
Technical data
- identical equipment

Complete formatting, laminating and postforming line
consisting of:
Roller conveyor system
Manufacturer: Kraft
Year of manufacture: 2019
Technical data
- 3 individual elements
- centering station

Double end profiler
Manufacturer: IMA
Type: FBA/II/740/A
Year of manufacture: 2018
Technical data
- equipped with infeed conveyor and aligning station
- saw unit below
- trimming unit
- edge trimming unit
- prism milling cutter
- joint milling cutter
- cross edge milling unit
- 3 profile milling units
- brushes

Laminating line
consisting of:
Infeed conveyor
Manufacturer: Kraft
Year of manufacture: 2019
Glue application machine
Manufacturer: Bürkle
Type: DAK1300
Year of manufacture: 1992
Technical data
- mechanically overhauled in 2018
- control system completely overhauled in 2022
- with infeed table, manufacturer Kraft
- steel platform with stairs and various pumps
- glue melting unit GWK Eco 03A

Infeed table for laminating line
Manufacturer: Kraft
Year of manufacture: 2019
Laminating line
Manufacturer: Bürkle
Type: EKMH 1300
Year of manufacture: 1998
Technical data
- new Siemens Simatic KMG Touch control system
- Bürkle GLK press calender
- incl. film holder and saw for overhang
- working width 1300 mm
- 2 temperature control units GWK
- column swivel crane for loading paper rolls
- extraction conveyor

Postforming line
Manufacturer: Homag
Technical data
- infeed table
- with 2 saw units, horizontal and vertical
- intermediate buffer with 4 levels
- infeed to the postforming machine
- 2 identically constructed processing sides with glue application
Hnsdpfx Anezuziyerer
- PU pre-melting unit Nordson / VersaBlue, year 2020 and 2004
- pressure zone with revolving magazine for various profiles
- various milling units and flap brushes
- 2 cooling units BEKO Bekoblizz LC, year 2020

Belt conveyor with inspection system
- swivel arm with vacuum suction cup
- inspection station for optical inspection of the workpiece

Portal destacking system
Manufacturer: Kraft
Technical data
- with vacuum portal and 3 destacking stations

Note:
The technical data and descriptions are copies of the original order confirmation. The information provided is for informational purposes only and is non-binding.
