POLSKA FABRYKA MASZYN CNC SENTINEL E

For sale: CNC milling plotter Sentinel E 1015, purchased for wood milling applications. In practice, the machine was used exclusively as a cutting machine for corrugated cardboard. It was not used for heavy-duty wood or metal processing, and its components were not subjected to loads associated with such milling.
Technical and visual condition: excellent.
Condition and usage history as declared by the seller.

P A R A M E T E R S / S E T C O N T E N T S
Specifications and equipment
ATC spindle, linear tool changer, and vacuum table with rotary vane pump.
Working area X: 1000 mm / Y: 1500 mm / Z: 300 mm
Kinematics: Linear guide
Linear transmission: Structural rocker system
ATC spindle: Power 8–9.6 kW; automatic tool change
Spindle parameters: 24,000 rpm; ceramic bearings; ER 32; ISO 30
Tool changer: Linear, for 6 tools
Drives: Digital AC servo drives: 4 × 400 W
Vacuum table: HPL plate
Machining technology: HSM (High Speed Machining)
Measuring systems: Material height sensor; tool length sensor
Tool cooling: Compressed air
Material clamping: 3-pin clamping system
Control: Control cabinet with computer, keyboard, and mouse
Tools and accessories included
Tool holders: Complete set of 6 ISO 30 tool holders
ER 32 collets: Ø 3, 4, 6, 10, 12, and 16 mm
Table accessories: Vacuum table seals: 30 m; 2 vacuum table supports
Rotary vane vacuum pump included
Model: C-VRL 301 Zephyr¹
Motor power: 5.5 kW
Nominal capacity: 290 m³/h
Final pressure: 150 hPa (mbar)
¹ Designating the pump according to the provided specifications; to be confirmed on the nameplate.
M A T E R I A L S / M A C H I N E D E T A I L S
Range of applications
Machining capabilities depend on the tool used, material thickness, operating parameters, and machine configuration.
Wood and wood-based boards: Wood, plywood, OSB, MDF, HDF.
Metals: Aluminum, brass, bronze, and other metals, depending on the selected machining technology.
Composites and technical boards: Composites, conglomerate, Corian, HPL, Dibond.
Plastics and modeling materials: Prolab, polyurethane foam, polystyrene, expanded PVC, Plexi, polycarbonate, acrylic.
Materials for cutting with an oscillating head²
Technical polyurethane foam, sponge, cardboard, corrugated board, film, leather, fabric, rubber, plastics; Kryngielit, Gambit, Polonit, and other materials and boards.
