Hurðapressubúnaður WILD (1998)

WILD

- Lengths: 1,800 - 2,300 mm
- Widths: 500 - 1,300 mm
- Thicknesses: 35 / 40 / 44 mm

Lodpfxozuzgro Aamshn
Door pressing system
Manufacturer: Wild
Year of manufacture: 1998
For door dimensions:
- Lengths: 1,800 - 2,300 mm
- Widths: 500 - 1,300 mm
- Thicknesses: 35 / 40 / 44 mm

Consisting of the following sections: 1. Continuous door panel gluing with frame assembly station / 2. Pressing line with hardboard facing station
Section 1 consists of:
- Gantry loading system
- Angle transfer with longitudinal and cross saws
- Loading and feeding of the longitudinal and transverse frame parts from magazines
- Longitudinal cutting station for the longitudinal frame parts
- Connecting station of the frame parts with the door panel core. With clamping devices
- Conveyor belt angle transfer with shuttle transfer of the door panel cores onto the glued hardboard

Section 2 consists of:
- Loading of the hardboard
- Brush cleaning machine
- Hardener application machine from below
- Glue application machine from below
- Roller conveyor
- Angle transfer for the lower hardboard
- Vacuum reversing device for the upper hardboard
- Automatic facing station for hardboard and door panel cores
- 2 door presses, each with 2 x 4 pressing stations, arranged parallel to each other
- Both presses are loaded at the infeed with 1 shuttle loading basket
- Both presses are unloaded at the outfeed with 1 shuttle unloading basket
- Angle transfer to the infeed into a hedgehog buffer
- Angle transfer at the outfeed of the hedgehog buffer and feeding to the stacking station
- One-sided vacuum stacking with protective plate space

Note:
The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.
